| CUADRO | Modelo | C:68X Monocoque Advanced Twin Mold Technology, ARG2, Internal Cable Routing, Dropper Post ready |
| Juego de dirección | Acros AzX/AiX, block lock, Top: semi 1 1/8", Bottom: 1 1/2" | |
| Caja de centros | PressFit BB | |
| Caño de asiento | Newmen Advanced Custom, Carbon, 27.2mm 400mm | |
| Abrazadera | CUBE Superlight, 30.8mm | |
| SUSPENSIÓN | Horquilla | RockShox SID SL Ultimate, Tapered, 15x110mm, 100mm, OneLoc |
| Amortiguador | - | |
| TRANSMISIÓN | Cadena | Sram PC-XX1 Eagle™ Rainbow |
| Descarrilador Trasero | Sram XX1 Eagle™, 12-Speed | |
| Descarrilador Delantero | - | |
| Shifters | Sram X01 Eagle™ Trigger | |
| Plato palanca | Sram XX1 Eagle™ DUB, 34T M:170mm L:175mm | |
| Piñon | Sram XG-1299 Eagle™ Rainbow, 10-52T | |
| FRENOS | Freno | Magura MT8 Pro PM, Hydr. Disc Brake |
| Rotores | (180/160) | |
| Levas de freno | Magura MT8 Pro | |
| COMPONENTES | Asiento | Natural Fit Nuance SL |
| Avance | Newmen Evolution SL 318.4, 31.8mm 6° M-L:80mm | |
| Puños | Natural Fit MTB Performance Lock On | |
| Manillar | Newmen Advanced 318.0, Carbon, 740mm | |
| RUEDAS | Maza delantera | 15x110mm |
| Maza trasera | Boost 12x148mm, | |
| Rayos | 28/28 Spokes | |
| Aros | Newmen Evolution SL X.A.25, Tubeless Ready | |
| Cubiertas Trasera | Schwalbe Racing Ralph, Super Race, Addix Speedgrip, Kevlar, 2.25 | |
| Cubierta Delantera | Schwalbe Racing Ray, Super Race, Addix Speedgrip, Kevlar, 2.25 | |
| ACCESORIOS | Pedales | - |
| PESO | 9 kg |
| Talle cuadro | S-16" | M-18" | L-20" | XL-22" | |
| Rodado | 29" | 29" | 29" | 29" | |
| ST | Tubo Asiento (mm) | 370 | 420 | 470 | 515 |
| TT | Tubo horizontal(mm) | 575 | 600 | 625 | 650 |
| CS | Largo de cadena (mm) | 424 | 424 | 424 | 424 |
| HTA | Angulo tubo dirección (°) | 69 | 69 | 69 | 69 |
| STA | Angulo tubo de asiento (°) | 73,8 | 73,8 | 73,8 | 73,8 |
| BD | Drop caja de centros/frenos (mm) | 63 | 63 | 63 | 63 |
| HT | Tubo de dirección (mm) | 90 | 98 | 111 | 129 |
| FL | Largo horquilla(mm) | - | - | - | - |
| HW | Largo Manillar | 740 | 740 | 740 | 740 |
| DS | Diametro Caño de Asiento | 27.2 | 27.2 | 27.2 | 27.2 |
| LS | Largo Caño de Asiento | 400 | 400 | 400 | 400 |
| SL | Largo Avance | 70 | 80 | 80 | 90 |
| AS | Angulo Avance | 6 | 6 | 6 | 6 |
| R | Alcance(mm) | 401.7 | 424.4 | 445.6 | 465.5 |
| CL | Largo Palanca | 170 | 170 | 175 | 175 |
| S | Drop caja de centros/manillar (mm) | 602.4 | 609.9 | 622 | 638.9 |
| WB | Distancia entre ejes (mm) | 1077.1 | 1102.6 | 1128.4 | 1154.5 |
| SH | Altura al piso (mm) | 739 | 750 | 781 | 804 |
